• Universal Powerful Granulator - WS-6550

Universal Powerful Granulator - WS-6550

Motor : 100~125HP
Infeed Opening : 1270 x 690mm
Production Rate : 1200~1700kgs
WS-6550 Infeed conveyor (optional)
Material blower (optional)
Cyclone separator (optional)
Model : WS-6550

Features

  • This machine is suitable for crushing heavy wastes.
  • Available to equip with various optional equipment for automated operations.
  • Material hopper elevation is operated by pneumatic cylinder, providing convenient knife change, maintenance, and material cleaning.
  • The infeed conveyor permits automatic material feed for operation convenience and labor saving. The material suction device combined with cyclone separator ar outfeed end permit the crushed material to be filled into bag directly.

Sample

Unit:mm
Model Motor (HP) Infeed Opening Rotating Knives Fixed Knives Machine Dimensions Machine Weights (kgs) Production Rate kgs/hr Accessories
C Type B Type L W H
WS-500 30~40 520x500 15 6 4 2000 1300 2200 2500 500~1000 2-step starting switch
Cooling device
WS-750 50~60 770x500 27 9 8 2000 1550 2200 3000 600~1200
WS-1000 75~100 1020x500 33 12 8 2200 1800 2300 4000 700~1400
WS-1250 100~125 1270x500 39 15 8 2200 2050 2300 5000 800~1800
WS-6530 60~75 770x690 27 9 8 2400 1675 2400 4000 800~1200
WS-6540 75~100 1020x690 33 12 8 2400 1925 2400 5000 1000~1500
WS-6550 100~125 1270x690 39 15 8 2400 2175 2400 5500 1200~1700
WS-6560 125~150 1520x690 45 18 12 2400 2425 2400 6000 1500~2000

* The above specifications are subject to change without prior notice.
* Production rate may be varied with actual operation conditions.
